Engine

Engine - 2.3L EcoBoost (231kW & 314PS)

Source configuration appliesSource reference 4,945HTML edition
← Chapter contentsManual collection
Engine — original illustration 1, reference 4945Original colors & callouts · Select to enlarge

136. Install the turbocharger and the nuts.

Torque

: 37 lb.ft (50 Nm)

Engine — original illustration 2, reference 4945Original colors & callouts · Select to enlarge

137. Position the turbocharger vacuum valve and install the nuts.

Torque

: 89 lb.in (10 Nm)
