NOTE: Make sure to minimize damage to sealer foam and avoid pulling apart dash seal brackets from retainer pins. Excessive damage may allow engine noise, fumes, air or water to enter the passenger compartment.
7.
1. Remove the steering column dash seal nuts.
2. Loosen the dash seal.
3. Hand start the dash seal nuts.
8. Using a holding device, hold the steering wheel in the straight-ahead position.
