Oil Pump — Removal — Engine - 3.7L Duratec (227kW & 301PS) · Reference 5150

Oil Pump — original illustration 1, reference 5150Original colors & callouts · Select to enlarge

6-Speed Automatic Transmission - 6R80/6-Speed Manual Transmission - MT82

NOTE: Make sure to minimize damage to sealer foam and avoid pulling apart dash seal brackets from retainer pins. Excessive damage may allow engine noise, fumes, air or water to enter the passenger compartment.

1. Remove the steering column dash seal nuts.

2. Loosen the dash seal.

3. Hand start the dash seal nuts.

Oil Pump — original illustration 2, reference 5150Original colors & callouts · Select to enlarge

Ford_Mustang_all_2015-2017.pdf · source reference 5150
