Engine — Engine - 3.7L Duratec (227kW & 301PS) · Reference 5402

Engine — original illustration 1, reference 5402Original colors & callouts · Select to enlarge

NOTE: Apply clean engine oil to the CMP sensor O-ring seals.

106. Install the CMP sensors and the bolts.

Material

: Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil (U.S.) / XO-5W20-QSP (U.S.) (WSS-M2C945-A)

Torque

: 89 lb.in (10 Nm)

Engine — original illustration 2, reference 5402Original colors & callouts · Select to enlarge

107. Install the RH block coolant drain plug.

Torque:

Stage 1: 142 lb.in (16 Nm)

Stage 2: 180°

Ford_Mustang_all_2015-2017.pdf · source reference 5402
