Engine — Engine - 3.7L Duratec (227kW & 301PS) · Reference 5431

Engine — original illustration 1, reference 5431Original colors & callouts · Select to enlarge

6-Speed Manual Transmission - MT82

3. Lubricate the input shaft with multi-purpose grease.

Material

: Motorcraft® Multi-Purpose Grease Spray / XL-5-A (ESB-M1C93-B)

Engine — original illustration 2, reference 5431Original colors & callouts · Select to enlarge

6-Speed Automatic Transmission - 6R80/6-Speed Manual Transmission - MT82

4. Using the floor crane, install the engine.

Use the General Equipment: Floor Crane
