14. Remove the bolt and separate the CAC from the radiator.

Torque

: 53 lb.in (6 Nm)

Thermostat Housing — original illustration 1, reference 5889Original colors & callouts · Select to enlarge

REMOVAL AND INSTALLATION > RADIATOR > INSTALLATION

1. To install, reverse the removal procedure.

2. Fill and bleed the cooling system. Refer to: Cooling System Draining and Vacuum Filling .

REMOVAL AND INSTALLATION > THERMOSTAT HOUSING

Special Tool(s) / General Equipment

Hose Clamp Remover/Installer

REMOVAL AND INSTALLATION > THERMOSTAT HOUSING > REMOVAL

NOTE: Removal steps in this procedure may contain installation details.

1. Drain the cooling system. Refer to: Cooling System Draining and Vacuum Filling .

2. Remove the nuts and the engine appearance cover.
