REMOVAL AND INSTALLATION > CYLINDER HEAD TEMPERATURE (CHT) SENSOR >

INSTALLATION

1. To install, reverse the removal procedure.

REMOVAL AND INSTALLATION > HEATED OXYGEN SENSOR (HO2S)

Special Tool(s) / General Equipment

303-476 (T94P-9472-A) Socket, Exhaust Gas Oxygen Sensor

Heated Oxygen Sensor (Ho2s) — original illustration 2, reference 6367Original colors & callouts · Select to enlarge

TKIT-1994-F

TKIT-1994-FLM/FM

TKIT-1994-LM/M

Materials

Name	Specification
High Temperature Nickel Anti-Seize Lubricant XL-2	-
Penetrating and Lock Lubricant XL-1	-

REMOVAL AND INSTALLATION > HEATED OXYGEN SENSOR (HO2S) > REMOVAL

All sensors
