Removal

Electronic Engine Controls - 3.7L Duratec (227kW & 301PS)

Source configuration appliesSource reference 6,375HTML edition
← Chapter contentsManual collection

REMOVAL AND INSTALLATION > MANIFOLD ABSOLUTE PRESSURE AND

TEMPERATURE (MAPT) SENSOR > INSTALLATION

NOTE: Second fastener hole available for use during re-install if needed.

1. To install, reverse the removal procedure.

REMOVAL AND INSTALLATION > POWERTRAIN CONTROL MODULE (PCM) >

REMOVAL

NOTE: This step is only necessary when installing a new component.

NOTE: PCM installation DOES NOT require new keys or programming of keys, only a Parameter Reset of the PATS.

1. Download the module information to the diagnostic tool using the PMI routine. Refer to: MODULE CONFIGURATION .

2. Unclip and position aside the BJB.

Removal — original illustration 1, reference 6375Original colors & callouts · Select to enlarge

3.

1. Disconnect the PCM electrical connectors.

2.
