Instrument Panel — 2016 workshop reference 1339

Instrument Panel — original illustration 1, reference 1339Original colors & callouts · Select to enlarge

32. Remove the LH instrument panel bolts. Torque : 16 lb.ft (22 Nm)

Instrument Panel — original illustration 2, reference 1339Original colors & callouts · Select to enlarge

33. Remove the RH instrument panel bolt. Torque : 16 lb.ft (22 Nm)
