Engine Front Cover — 2016 workshop reference 210

Engine Front Cover — original illustration 1, reference 210Original colors & callouts · Select to enlarge

20. Remove the nut, the bolt and position the generator aside.

Engine Front Cover — original illustration 2, reference 210Original colors & callouts · Select to enlarge

21. NOTE: Vehicles are equipped with either an underbody shield or a subframe bracket and underbody shield assembly.

1. Remove the bolts and the underbody shield.

2. Remove the bolts and the subframe bracket and underbody shield assembly.
