Installation
WARNING: Incorrect repair techniques or actions can cause an accidental Supplemental Restraint System deployment. Make sure the restraint system is depowered before reconnecting the component. Refer to the Supplemental Restraint System depowering General Procedure in section 501-20B. Failure to precisely follow depowering instructions could result in serious personal injury from an accidental deployment.
WARNING: Before installing a Safety Canopy® or side air curtain module, inspect the roofline for any damage. If necessary, the sheet metal must be reworked to its original condition and structural integrity. Install new fasteners if damaged and remove foreign material. Failure to follow these instructions may result in the Safety Canopy® or side air curtain deploying incorrectly, which increases the risk of serious personal injury or death in a crash.
NOTE: During installation, ensure that the side curtain airbag is not twisted 360° between attachment points.
1. To install, reverse the removal procedure.
2. Tighten the screws in the sequence shown.
1. Tighten screws 1 and 2. Torque : 106 lb.in (12 Nm)
2. Tighten screws 3 through 7. Torque : 80 lb.in (9 Nm)
