Rear Subframe — 2016 workshop reference 2393

Rear Subframe — original illustration 1, reference 2393Original colors & callouts · Select to enlarge

9. If equipped.

1. Install the differential cooling supply line.

2. Install the differential cooling supply line retaining clip.

Rear Subframe — original illustration 2, reference 2393Original colors & callouts · Select to enlarge

10. If equipped.

1. Install the differential cooling return line.

2. Install the differential cooling return line retaining clip.

Source reference 2393
