Rear Subframe — 2016 workshop reference 2394

Rear Subframe — original illustration 1, reference 2394Original colors & callouts · Select to enlarge

11. Position the driveshaft to the pinion flange and align the index mark made during removal.

Rear Subframe — original illustration 2, reference 2394Original colors & callouts · Select to enlarge

12. Install the driveshaft-to-pinion flange bolts. Torque : 41 lb.ft (55 Nm)

Source reference 2394
