Oil Pan — 2016 workshop reference 330

Oil Pan — original illustration 1, reference 330Original colors & callouts · Select to enlarge

37. Remove the holding device.

Oil Pan — original illustration 2, reference 330Original colors & callouts · Select to enlarge

Step 38

1. Position the steering column dash seal.

2. Tighten the steering column dash seal nuts. Torque : 80 lb.in (9 Nm)

Source reference 330
