10. WARNING: Do not reuse steering column shaft bolts. This may result in fastener failure and
steering column shaft detachment or loss of steering control. Failure to follow this instruction may result in serious injury to vehicle occupant(s).
NOTICE: DO NOT hammer, pry or force steering column and column shafts during installation or removal. Failure to follow this instruction may cause damage to steering components that could lead to loss of steering control during vehicle operation and could result in serious personal injury or death.
NOTICE: DO NOT attempt to remove or install the steering column lower coupler at the steering gear without first loosening the steering column dash seal and fasteners. Failure to follow this instruction may cause damage to steering components that could lead to loss of steering control during vehicle operation and could result in serious personal injury or death.
Detach the steering column lower shaft from the lower coupler.
1. Remove and discard the steering column shaft bolt.
2. Pull apart the steering column shaft from the coupler.
3. Secure the lower shaft to the frame rail to avoid damaging it during steering gear removal.
