3 | RPW03 (BU-GN) | 22 | CTRL MOD. - POWER WINDOW SWITCH DRIVER RETURN |
4 | CPL77 (BU) | 26 | CTRL MOD. - DOOR LOCK # SWITCH TRIM DOOR LOCK DRIVER ILLUMINATION |
5 | CPS15 (VT-WH) | 22 | SWITCH - MEMORY DRIVER P1 |
6 | CPS16 (YE-VT) | 22 | SWITCH - MEMORY DRIVER P2 |
7 | CPS17 (BU-OG) | 22 | SWITCH - MEMORY DRIVER P3 |
8 | * | * | Not Used |
Available Pigtail Kits
Service Part Number:
3U2Z-14S411-DAAC
Pigtail Kit Part Number
Gauge:
WPT-1219
18
Pin material:
Silver
Cavities:
8
Vehicle Uses
Switch - Ambient Lighting Dimmer
Switch - Door Lock (LH)
Switch - Message Center
Switch - Moon Roof/Sun Roof
Switch - Seat Memory
