Engine

Engine - 2.3L EcoBoost (231kW & 314PS)

Source configuration appliesSource reference 4,817HTML edition
← Chapter contentsManual collection
Engine — original illustration 1, reference 4817Original colors & callouts · Select to enlarge

52. Remove the high-pressure fuel pump tappet.

Engine — original illustration 2, reference 4817Original colors & callouts · Select to enlarge

53. Remove the stud bolts and the high-pressure fuel pump drive unit.

Ford_Mustang_all_2015-2017.pdf · source reference 4817
