Cylinder Head LH — Installation — Engine - 3.7L Duratec (227kW & 301PS) · Reference 5047

Cylinder Head LH — original illustration 1, reference 5047Original colors & callouts · Select to enlarge

NOTE: Do not lubricate the engine oil filter seal.

15. Install a new engine oil filter.

Torque:

Stage 1: 44 lb.in (5 Nm)

Stage 2: 180°

Cylinder Head LH — original illustration 2, reference 5047Original colors & callouts · Select to enlarge

16. Fill the engine with clean engine oil. Refer to: Specifications .

Material

: Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil (U.S.) / XO-5W20-QSP (U.S.) (WSS-M2C945-A)
