Engine — original illustration 1, reference 5283Original colors & callouts · Select to enlarge

27. Disconnect the EVAP canister purge valve electrical connector and wire retainer.

Engine — original illustration 2, reference 5283Original colors & callouts · Select to enlarge

28. Disconnect the throttle body electrical connector and wire retainer.

Engine — original illustration 3, reference 5283Original colors & callouts · Select to enlarge

29. Disconnect the MAPT sensor and wire retainer.
